Home > Products > Carrier Vehicle > Dongfeng Duolika DFA1040S30DB.....
Dongfeng Duolika  DFA1040S30DB Single-row Rack Body TruckDongfeng Duolika  DFA1040S30DB Single-row Rack Body TruckDongfeng Duolika  DFA1040S30DB Single-row Rack Body TruckDongfeng Duolika  DFA1040S30DB Single-row Rack Body TruckDongfeng Duolika  DFA1040S30DB Single-row Rack Body Truck

Dongfeng Duolika DFA1040S30DB Single-row Rack Body Truck

  • 1.model number:DFA1040S30DB
  • 2.drive type:4*2
  • 3.engine:changchai4F20BTCI
  • 4.rated loading capacity:1495t
  • 5.fuel type:diesel
  • 6.emission standard:Euro4
  • 7.displacement:1.995L
  • 8.max output:50kw
  • 9.max speed:90km/h

model number:DFA1040S30DB         drive type:4*2              engine:changchai4F20BTCI
rated loading capacity:1495t       fuel type:diesel            emission standard:Euro4
displacement:1.995L                max output:50kw             max speed:90km/h








BASIC PARAMETER
model number DFA1040S30DB
drive type 4*2
engine changchai4F20BTCI
overall dimension 5192*1950*2115
wheelbase 2800mm
F/Rwheel-base 1445mm/1458mm
G.V.W 3725kg
rated loading capacity 1495kg
curb weight 2100kg
max speed 90km/h
ENGINE
engine changchai4F20BTCI
fuel type diesel
displacement 1.995L
max output 50kw
emission standard Euro4
max horse power 68
max torque speed 2200RPM
torque 170N.m
rotation rate 3200RPM
running gear
transmission type manual
forward gear 5
number of reverse gear 1
TIRE
tire specification 6.50R16
tire numbers 6
CARGO BOX
type rack-body truck
dimension 3500*1800*400
CHASISS
front axle capacity 1380kg
rear axle capacity 2345kg
leaf spring 5/7+3

Brief Introduction:

 Miou is located in Shiyan, Hubei province, China.Our company is specialized in R & D,manufacture and sales of special purpose vehicles .We are the special purpose vehicles production base company of the Chinese Dongfeng Motor Group and also the Overseas Department of Dongfeng Zhengmeng Special Purpose Vehicle Co., Ltd.



Company Display:



Factory Display:



Packing:  nude, covered with wax, small type can be put into 20'GP or 40'GP, big type can be carried by bulk carriers or ro-ro ship or according to your requirements

Delivery date: 15 days






Q:How about the warranty?

A:One year



Q:Do you have ISO certificate ?

A:Yes , we have,pls contact us to get our certifications.



Q:How about the delivery time?

A: Most of our trucks are all have in stock ,We can delivery to you within 15 days, if specially ordered , we always need around 30 days for production.



Q:How about shipping ?

A:Big size trucks always shipping by RORO or Bulk ship or flat bed container or open top container , small type can shipping by container ,Pls contact us to get a shipping quotation .



Q: How many trucks does your factory produce per years?

A:Almost 3000 units



Q: How do you control the quality of product?

A:Our Factory is standard production workship,got ISO CCC BV Certification,our workers are well trained. Our very product under goes a scrutinizing inspection process.



Q: How about your product After-sales service system?

A:Our main export country have accepted after-sales service,some of country used the third department service.



Q: Do you accept Custom orders? What’s is your MOQ order?

A:Yes, we do, our MOQ is 1 set.



Q: What’s the payment terms?

A:By T/T or L/C at sight.



Q:Which country do you have exported to?

A: our special trucks can be found in many parts of the world,  such as Russia, Ukraine, Kazakhstan, Azerbaijan, Iran, Iraq, Algeria, Turkey, Brazil, Thailand, Vietnam, Angola etc, and gain good reputation from local market.




We provide you sincerely serviceif you have interest,contact us now!





Remarks:

    The above information is just for your reference. We can manufacture the trucks as per your request and we can fulfill all your demands.
