Drive Wheel:

6*4

Fuel:

Diesel

Transmission Type:

Manual

Condition:

New

Sprinkling Area (m):

8 - 12m

Emission Standard:

Euro 3

Engine Capacity:

< 4L

Tank Volume:

5001 - 10000L

DMS (L x W x H) (mm):

9950*2490*3350

Gross Vehicle Weight:

9500

Water truck brand.:

DongFeng

Warranty:

one year

water tank truck Wheels:

6 wheels.

Water truck engine:

Cummins

Steering:

LHD or RHD.

water truck

Item

Unit

Description

Model

Dong Feng brand Water Tank Truck

Dimension

mm

9950*2490*3350

Tank Dimension

mm

6500*2360*1550/ 20 m3

Option: 18~22 cubic meter, To be confirmed

Curb Weight

kg

9005

Wheel Base

mm

4350+1350

F/R track base

mm

1940/1860

F/R Axle-load

Kg

7000/11000( Tow 11 tons  axles concatenation)

Approach/Departure angle

.

28/10

Traction system

6x4

Tire Specification/Number

10.00-20 / 10 Units+1Spare Unit

Max speed

90 km/h

Number of axles

3

Engine model

B210-33

Emission/kw

5900ml/162Kw,210Hp

Diesel, 6 cylinder , direct-line, turbocharge and water cooling.

Engine Manufacturer

Dongfeng Cummins Diesel Co.,Ltd

Option~ E4, E5 emission standard engine

Steering

Power

Transmission

DF9S1600, 9F&1R

China

Dong Feng brand

Cab passenger

3

Electric System

24V

Dirve system

left hand or Right hand

Air Condition

Option

Radio, CD.

Remark:

Installing water pump to loading or discharge water, side input and output port. Electronic window, Air driven seat.Front and rear water spraying port.

Option~340 USD if installed air condition.

Option~300 USD if installing beam alarm light, 100 USD installing dot alarm light.rear LED alarm light.
